Model: SB-CS-IN24 Date Code: 20160928

Description: The Smart-Bus G5 24-Channel Current Sensor Input Module is a high-performance current monitoring solution for advanced building automation systems. Designed to detect the ON/OFF status of multiple electrical loads, it integrates seamlessly with Smart-Bus G5 controllers to provide real-time energy monitoring, load detection, and equipment status feedback. Ideal for managing lighting circuits, HVAC systems, audio-video equipment, pumps, and motors, this DIN-rail mountable device offers precise current sensing across 24 channels, ensuring efficient energy use and enabling smart automation triggers.

Key Features:

• 24 individual current sensor inputs (IN1–IN24) for multi-circuit monitoring.
• Detects current draw to confirm device or circuit status.
• Seamless integration with Smart-Bus G5 automation systems.
• Ideal for load monitoring in residential, commercial, or industrial projects.
• Real-time feedback for intelligent automation rules.
• 24V DC powered via Smart-Bus connection.
• Compact, durable DIN-rail mountable housing.

Applications:

• Lighting automation and status detection.
• HVAC and air conditioning system monitoring.
• Audio-visual equipment power tracking.
• Pump and motor operation feedback.
• Energy efficiency and load management systems.

Technical Specifications:

• Inputs: 24 × current sensor channels.
• Detection Range: Supports low to moderate AC current sensing (exact range depends on connected sensors).
• Bus Protocol: Smart-Bus G5.
• Power Supply: 24 V DC (via Smart-Bus).
• Mounting: DIN-rail.
• Material: Heat-resistant ABS plastic.
