The FTP9T is an advanced fan coil thermostat panel designed for precise temperature regulation in smart homes, hotels, offices, and commercial buildings. With its sleek touchscreen interface, it offers intuitive climate control for fan coil units, ensuring optimal comfort and energy efficiency.

Engineered for seamless integration with building automation systems, the FTP9T supports multiple fan speeds, heating/cooling modes, and programmable scheduling, making it ideal for both individual rooms and centralized HVAC systems. Its modern design blends effortlessly into any interior while delivering professional-grade performance.

Key Features

• Touchscreen control panel with modern, intuitive UI
• Supports multiple fan coil unit types (2-pipe / 4-pipe systems)
• Adjustable fan speeds: low, medium, high, or auto mode
• Heating, cooling, and ventilation modes
• Programmable temperature schedules for energy savings
• Seamless integration with BACnet / Modbus / proprietary automation protocols
• Real-time temperature and humidity display
• Energy-efficient operation with intelligent load control
• Wall-mounted design with slim profile
• Backlit display for easy visibility in all lighting conditions

Applications

• Hotel room climate control for guest comfort
• Office HVAC management in individual zones
• Smart home temperature regulation
• Commercial building energy optimization
• Conference rooms and meeting halls for custom climate settings

Technical Specifications – FTP9T

• Display: Capacitive touchscreen, backlit
• Temperature Range: 5°C to 35°C
• Control Output: Fan coil control (2-pipe / 4-pipe)
• Fan Speeds: Low / Medium / High / Auto
• Power Supply: 100–240 V AC or 24 V DC (model-dependent)
• Communication: RS485 (Modbus/BACnet), optional Wi-Fi
• Mounting: Standard wall box installation
• Dimensions: Slim, compact panel design
• Enclosure: Durable ABS with glass panel
• Operating Temperature: 0°C to 50°C
• Certifications: CE, RoHS
